Genset Isuzu 40 Kva, Isuzu Power IP-40
Genset Isuzu 40 KVA hadir sebagai solusi listrik andal untuk kebutuhan industri, menggunakan mesin Isuzu JE493ZLDBE-02 berpendingin air yang dipadukan dengan kontroler DeepSea DSE4620. Ditenagai mesin 4 silinder dengan kecepatan 1500 rpm, genset ini menawarkan konsumsi bahan bakar efisien sekitar 7,6 liter per jam serta tangki berkapasitas 60,7 liter. Didukung alternator Isuzu Power dengan daya hingga 34 kW, genset ini memberikan performa stabil, daya tahan tinggi, dan telah memenuhi standar emisi Stage II.
SpESIFICATIONS
| Spesification | |
|---|---|
| Tipe | IP40 |
| Rated Output | 32 KW / 40 KVA |
| Standby Output | 35,2 KW / 44 KVA |
| Controller | |
| Brand / Model | DeepSea (DSE4620) |
| Battery | Maintenance Free, dengan charger |
| Engine | |
| Brand / Model | ISUZU / JE493ZLDBE-02 |
| Tipe | In line, 4 Cylinder, 4 Stroke |
| Air Intake | Naturally Aspirated |
| Cooling | Water Cooling |
| Governor | Electronic |
| Bore × Stroke | 93 × 102 mm |
| Compression Ratio | 18.2:1 |
| Rated Speed | 1500 rpm |
| Displacement | 2,771 L |
| Rated Power (No Fan) | 38 KW |
| Standby Power (No Fan) | 42 KW |
| Fuel Consumption | 210 g/KWh | 8,1 L/h |
| Fuel Tank Capacity | 64,8 L |
| Speed Regulation | ≤ 5% |
| Emission | Stage II |
| Alternator | |
| Model | ISUZU POWER |
| Output | 34 KW |
| Voltage / Frequency | 400V / 230V, 3 Phase, 50 Hz, cosΦ 0.8 |
| Insulating Grade | H |
| Protection Grade | IP23 |
| Dimensi & Berat | |
| Packing Size | 2280 × 1000 × 1280 mm |
| Berat | 990 kg |
